PbS- and PbSe-Detectors from Opto Diode
40029
Opto Diode develops and manufactures Silicon Photodiodes, Photodiode amplifier combinations, PbS and PbSe Detectors and LEDs. Development, Waferfab and Assembly are located in Camarillo/California.
Typical applications for their products include photo-electric controls; medical, scientific and industrial fluorescence; guided missile systems, ophthalmology, LED based tracking systems for surgery, vending machines and aviation lighting. A small portfolio of standard components gives an impression of the design and production capabilities of Opto Diode.
Developing customized chip geometries belongs to Opto Diode’s daily business. A cost-efficient devlopment in short time avoids unnecessary compromises and offers the perfect solution for each specific task.
Markets
Emission monitoring
Spectroscopy
Control systems
Thermal monitoring
Flame monitoring and detection
Safety and Security
Applications
Flame Detection
Features
Sensitivity range 1000 nm – 3000 nm
Optimized for the NIR-range
Dimension of the sensitive area 3 x 3 mm
Benefits
- Specifications
- Data Sheets
- Videos
Additional information
| Manufacturer | Opto Diode |
|---|---|
| Part Number | 40029 |
| Product Group | PbS and PbSe Detectors |
| Products | PbS- and PbSe-Detectors |
| Channels | 1 |
| Wavelength Range | NIR |
| Technology | PbS |
| Lower Wavelength in nm | 1000 |
| Upper Wavelength in nm | 3000 |
| Peak Wavelength in nm | 2700 |
| Dim. of Active Area in mm | 3 x 3 |
| Design | TO |
| Package | TO8 |
| Responsivity in V/W | 4,3x 10^5 |
| D* in cm√Hz/W | 3,0x 10^11 |
| Rise Time in ns | 1750000 |
| TEC & Thermistor | Two-Stage |
